. DUAL GSM TELEPHONE SGH-2488 OWNER’S MANUAL. 2488E-00-Contents 6/7/00 9:57 PM C o n t e n t s Safety Precautions.7 Unpacking.9 Your Phone.10 Phone Layout.10 Display. 2488E-00-Contents 6/7/00 9:57 PM In-Call Options.63 Switching the Microphone Off (Mute).63 Searching for a Number in the Phonebook. 64 Putting a Call on Hold.65 Answering a Second Call. 2488E-00-Contents 6/7/00 9:57 PM Page 6 Security.115 PIN Check (Menu 8-1).115 Change PIN (Menu 8-2).116 Phone Lock (Menu 8-3). 2488E-01-SafetyPrecaution 6/7/00 Safety Precautions Read these simple guidelines.

• Samsung Sgh 2488 Service Manual Pdf
• Samsung Sgh 2488 Service Manual

Failure to comply with them may be dangerous or illegal. For more detailed safety information, see Safety Information on page 133. Road safety comes first Do not use a hand-held phone while driving; park the vehicle first. Your package contains the following items.

Give your location. In addition, you can obtain the following accessories for your phone from your local SAMSUNG dealer:. Cigarette lighter adapter (CLA12). Hands-free car kit (HFK240). Slim, Standard, and Extended batteries.

2488E-02-YourPhone 6/7/00 9:00 PM Your Phone Phone Layout The following illustration shows the main elements of your phone. Service light Earphone jack Volume/menu scroll keys Soft key (left) Dial/menu comfirmation Microphone Flip cover Page 10 (soft keys) Antenna Earpiece Display Cancel/Vibration/ correction key Soft key (right). 2488E-02-YourPhone 6/7/00 9:00 PM Your Phone Display Display Layout The display comprises three areas. Menu PhoneBook Area Description First line Displays various icons (see opposite). Middle lines Display messages, instructions and any information that you enter (number to be dialled, for example). Last line Shows the functions currently assigned to the two soft keys,. 2488E-02-YourPhone 6/7/00 9:00 PM Page 14 Your Phone Backlight The display and keypad are illuminated by a backlight.

Samsung Sgh 2488 Service Manual Pdf

When you press any key, the backlight illuminates. It turns off if no key is pressed within a given period of time, depending on the Backlight option set in the Phone Settings menu. 2488E-03-GettingStarted 6/7/00 Getting Started Your First Call The following diagram explains the main steps re q u i re d when making your first call and indicates the pages on which you can find more detailed instru c t i o n s. Insert the SIM card (phone switched off and battery removed). 2488E-03-GettingStarted 6/7/00 Getting Started Installing the SIM Card When you subscribe to a cellular network, you are p rovided with a plug-in SIM card loaded with your subscription details (PIN, optional services available and so on). I m p o rt a n t!

The plug-in SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, i n s e rting or removing the card. 9:00 PM Page 18 Charging a Battery Use only Samsung-approved chargers and adapters with your phone. Use of any unauthorized accessories may be dangerous and will invalidate the phone warranty if the accessories cause damage or a defect to the phone.

2488E-03-GettingStarted 6/7/00 Getting Started Low Battery Indicator When the battery is weak and only a few minutes of talk time remain, you will hear a warning tone and a message will be repeated at regular intervals on the display:.Warning. Battery Low When the battery becomes too weak for the phone to operate, it switches off automatically. 2488E-03-GettingStarted 6/7/00 Getting Started Access Codes T h e re are several access codes that are used by your phone and its SIM card. These codes help you pro t e c t the phone against unauthorised use. When requested for any of the codes explained below, key in the appropriate code (displayed as asterisks) and press the OK soft key.

2488E-03-GettingStarted 6/7/00 Getting Started PIN2 The PIN2 (4 to 8 digits), supplied with some SIM c a rds, is re q u i red to access specific functions, such as setting the maximum cost of a call. These functions a re available if supported by your SIM card. If you enter an incor rect PIN2 three times in succession, the code is disabled and you cannot access the functions until you re-enable it.

2488E-04-GeneralFunctions 6/7/00 General Functions Making a Call When the idle screen is displayed, key in the area code and phone number and press N o t e: If you have set the Auto Redial option (6 - 7) to O N (see page 102) and the person called does not answer or is already on the phone, the number is redialled automatically up to ten times. 2488E-04-GeneralFunctions 6/7/00 General Functions 2. Hold down to display the last number dialled.

Use the soft key (or of the phone) to scroll through the numbers until the required number is displayed. Press to dial the number displayed. Adjusting the Volume During a call, if you want to adjust the earpiece volume, use the volume keys on the left side of the. 2488E-04-GeneralFunctions 6/7/00 General Functions Viewing Missed Calls If you are unable to answer a call for any reason, you can find out who was calling you, if this service is available. In this way, you can call the person back, if necessary.

2488E-05-SelectingFunctions 6/7/00 Selecting Functions and Options Your phone offers a set of functions that allow you to customise your phone. These functions are arranged in menus and sub-menus, accessed via the two soft keys marked.Each menu and sub-menu allows you to view and alter the settings of a particular function.

2488E-05-SelectingFunctions 6/7/00 Selecting Functions and Options Example: Setting the Text Language 1. When the idle screen is displayed, press the Menu soft key to enter the menu facility. Fri 15 May 10:30 Menu PhoneBook 2. Scroll through the menus until you reach the Phone Settings menu, by pressing the key (or the keys on the left side of the. 2488E-06-Phonebook 6/7/00 9:00 PM P h o n e b o o k You can store phone numbers and their corresponding names in the memory of your SIM card.

In addition, you can store up to 100 numbers and names in the phone memory. 2488E-06-Phonebook 6/7/00 9:00 PM P h o n e b o o k 3. Then press the. View the View soft key.

Highlighted entry Select a soft key (or the different entry keys on the left side of the phone) one or more times until the required entry is highlighted. 2488E-06-Phonebook 6/7/00 9:00 PM Page 40 P h o n e b o o k Paste This option allows you to paste the phonebook number into the normal dialling mode. Use this option to dial a number similar to one in the phonebook (a d i ff e re n t extension in the same office for example). 2488E-061-EnterText1 6/7/00 9:24 PM Page 41 Entering Text The phone allows you to enter characters for messages and names in Chinese and English. To enter Chinese text, the phone provides several widely used pronunciation based (Pinyin) and character shape based (Stroke) input methods to meet the preferences of different users, allowing for greater convenience and ease of use.

2488E-061-EnterText1 6/7/00 9:24 PM Entering Text Changing Text Input Mode When you are in a field that allows character entry, you should notice the text input mode indicator in the bottom of the display. Save Mode Text mode indicator You can change between Chinese input methods, and English or to numbers input. 2488E-061-EnterText1 6/7/00 9:24 PM Entering Text Pinyin( ) Mode Pinyin is a system to mark Chinese pronunciation in Latin alphabets. With the pinyin input method, you can enter Chinese characters by keying in the pinyin string from the phone keypad and the phone automatically presents the matching alternatives. 2488E-061-EnterText1 6/7/00 9:24 PM Entering Text Typing Characters in Pinyin Mode 1. Press keys corresponding to the phonetic spelling, referring to the Roman letters printed on the keys.

Notice that the choices in the Character Selection Map change. Example: Typing in Pinyin mode Mode Save. 2488E-061-EnterText1 6/7/00 9:25 PM Entering Text Using Tone Key in Pinyin Mode Entering the tone of a character you are typing narrows the number of choices in the Character Selection Map.

Entering the tone for a character is optional, but it is especially useful if the Pinyin spelling is similar between characters. 2488E-062-EnterText2 6/7/00 9:24 PM Entering Text Chnise Stroke( This mode allows you to enter individual Chinese strokes, in written order - from top to bottom, and from left to right. Your phone provides Chinese Simplified Stroke mode and Chinese Traditional Stroke mode. Text Area Displays the selected characters. 2488E-062-EnterText2 6/7/00 9:24 PM Entering Text Even though there are many different strokes used to create Chinese characters, the strokes are classified into 5 basic categories; heng, shu, pie, dian and zhe. The basic strokes are printed on the keypad, on keys To enter a stroke, press the key printed with the stroke that most closely represents the exact stroke you desire.

2488E-062-EnterText2 6/7/00 9:24 PM Entering Text 3. When the character you are typing appears in the Character Selection Map, you may select it without finishing the stroke sequence for the character. Characters displayed in the Character Selection Map correspond to keys select a character from the Character Selection Map and add it to your message, press the corresponding Note: If you are uncertain of the order of one or more. 2488E-062-EnterText2 6/7/00 9:24 PM Entering Text Quick English( This mode allows you to enter English words with only one keypress per letter.

Each key on a keypad has more than one letter - a single press on the key could be J, K, or L. The Quick English mode automatically compares your key presses to an internal Quick English linguistic database to determine the correct word. 2488E-062-EnterText2 6/7/00 9:24 PM Entering Text Typing English Words To type a word, press keys corresponding to the letters you need.

Samsung Sgh 2488 Service Manual

Remember the following as you are typing: 1. Press keys on the handset just once per desired letter. For example, to enter ‘hello’, press 2. 2488E-063-EnterText3 6/7/00 9:24 PM Entering Text English( ) Mode When typing in English mode, you should press key labelled with the required letter: -Once for the first letter -Twice for the second letter -And so on. For example, you press three times quickly to display the letter “C”.

2488E-063-EnterText3 6/7/00 9:24 PM Page 62 Entering Text Number Mode Number mode enables you to enter numbers into a text message. Press keys corresponding to the desired digits, and manually switch back to the text entry mode of choice. Symbolic Mode Symbolic mode enables you to enter symbols into a text message. 2488E-07-IncallOption 6/7/00 In-Call Options Your phone provides a number of control functions that you can use during a call.

To access these functions during a call, press the Options soft key. Switching the Microphone Off (Mute) You can temporarily switch your phone’s microphone off, so that the other party cannot hear you. 2488E-07-IncallOption 6/7/00 In-Call Options Searching for a Number in the Phonebook You can search for a number in the phonebook during a call.

Press the Options soft key. Press the soft key to highlight the Phonebook option. Press the OK soft key.

2488E-07-IncallOption 6/7/00 In-Call Options To swap between the two calls, simply press the Swap soft key. The current call is placed on hold and the call on hold is reactivated so that you can continue conversing with the other party. When you have finished, end each call normally by pressing the key. 2488E-07-IncallOption 6/7/00 In-Call Options 2. Highlight the required person, by pressing the soft key (or the keys on the side of the phone), followed by 3. Select Private. Now you can talk privately with that person.

The other participants can continue to converse with each other. 2488E-07-IncallOption 6/7/00 9:24 PM Page 70 In-Call Options. 2488E-08-UsingMenus 6/7/00 9:24 PM Using the Menus A three-level menu structure is available to set the various options available on your phone. You can select the menu options in two different ways. Using the Soft Keys The two soft keys are used as follows. Purpose Left soft key Enters the menu structure. 2488E-08-UsingMenus 6/7/00 9:24 PM Using the Menus Using the Index System Each menu option is assigned a hierarchical number.

You can use this number to access the corresponding option directly. Simply press the Menu soft key and key in the required number. Example: Connecting to your Voice Mail. 2488E-08-UsingMenus 6/7/00 9:24 PM Using the Menus 3. Text Messages 3-1 Read Messages 3-2 Write Messages 3-3 Preset Message List 3-4 Setup 3-4-1 Service Center 3-4-2 Default Type 3-4-3 Default Validity 3-5 Broadcast 3-5-1 Read 3-5-2 Receive 3-5-3 Channel List 3-5-4 Language 4. 2488E-08-UsingMenus 6/7/00 9:24 PM Using the Menus 9. Network Services 9-1 Call Diverting 9-1-1 Divert Always 9-1-2 Busy 9-1-3 No Reply 9-1-4 Unreachable 9-1-5 Cancel All 9-2 Call Barring 9-2-1 All Outgoing 9-2-2 International 9-2-3 International except to home 9-2-4 All Incoming 9-2-5 Incoming while abroad 9-2-6 Cancel All 9-2-7 Change Barring Password.

2488E-09-Menus1-2 6/7/00 9:05 PM Vocie Mail This menu provides you with a quick way of accessing your voice mailbox (if provided by your network). N o t e: Voice Mail is a network feature. Please contact your service provider for more inform a t i o n. Connect to Voice Mail Before using this feature, you must enter the voice server number obtained from your service provider. 2488E-09-Menus1-2 6/7/00 9:05 PM Voice Mail To. Then press the. Move the cursor to soft key.

The left without clearing the digit N o t e: See page 36 for instructions on how to use the p h o n e b o o k. Service Directory If your SIM contains Service Dialling Numbers (SDN), this menu enables you to view the Service Dire c t o ry. 2488E-09-Menus1-2 6/7/00 9:05 PM Call records Dialled Calls This option lets you view the last 10 numbers dialled. You can also:. Edit the number and save it in the phonebook.

Redial the number. Delete the number from the list Call Time This option lets you view the timers for calls made and received. 2488E-10-Menu3 6/7/00 9:31 PM Text Messages The SMS (Short Message Service) function is a network service and may not be supported by your network.

Messages can be sent by fax, E-mail, ERMES or X.400 messaging systems, provided that these s e rvices are supported by your network. To send text messages by phone, you must obtain the number of the SMS centre from your service pro v i d e r. 2488E-10-Menu3 6/7/00 9:31 PM Text Messages After you complete the message, you can select the following options. Send Only: allows you to:.

Enter the required destination. Enter or change the SMS centre number. Select the message format (Text, Voice, or Fax).

2488E-10-Menu3 6/7/00 9:31 PM Text Messages Default Validity: allows you to set the default time period for which your messages are stored in the SMS centre while attempts are made to deliver them. Possible values are one hour, six hours, 24 hours, one week and the maximum authorised by your service provider. 2488E-11-Menus4-5 6/7/00 9:31 PM Voice Functions You can use the Voice feature to customize various settings, such as the:.

Voice Dial. Voice Command. Voice Memo. AnswerPhone Voice Dial You can call up to 20 stored entries by speaking the name into micro p h o n e.

2488E-11-Menus4-5 6/7/00 9:31 PM Voice Functions Voice Dial Play All This option allows you to play back all recorded names. Voice Dial Delete All This option allows you to delete all voice dial information stored. The phone numbers remain in the phonebook but the voice recordings are deleted. 2488E-11-Menus4-5 6/7/00 9:31 PM Voice Functions If you want to record for longer, press the Continue soft key. Split appears instead of Continue.

You can continue recording and the rest of the memo is stored in the next memo location. To stop recording, press the Stop soft key. 2488E-11-Menus4-5 6/7/00 9:31 PM Sound Settings You can use the Sound Settings feature to customise various settings, such as the:. Ringing tone, volume and type. Composing your own melody. Sounds made when you press a key, make an error or receive a message Ring Tone This option allows you to select the required ringing.

2488E-11-Menus4-5 6/7/00 9:31 PM Sound Settings If you select No, the melody is just saved and the phone returns to the standby mode. To Delete a Selected Melody 1. Select the melody you want to delete. Press and hold the C button for a few seconds. All notes will be erased.

2488E-11-Menus4-5 6/7/00 9:31 PM Sound Settings Error Tone This option allows you to select how the phone informs you that you have made a mistake. The following options are available. OFF: the phone does not beep. ON: the phone beeps to indicate an invalid entry. Minute Minder This option allows you to specify whether the phone must beep every minute during an outgoing call to.

2488E-12-Menu6 6/7/00 9:31 PM Phone Settings Many diff e rent features of your phone can be customised to suit your pre f e rences. All of these f e a t u res are accessed via the Phone Settings m e n u. Greeting Message This option allows you to set a greeting message to be displayed briefly when the phone is switched on. 2488E-12-Menu6 6/7/00 9:31 PM Phone Settings To. Then press the. Enter the international 0 key and hold it prefix (+) down until the + is displayed.

Correct a digit C key. Clear the whole number C key and hold it down until the number is cleared. 2488E-12-Menu6 6/7/00 9:31 PM Phone Settings Auto Redial With the Auto Redial function, the phone makes up to ten attempts to redial a phone number after an unsuccessful call. N o t e: The interval between two call attempts varies. The following options are available. 2488E-13-Menus7 6/7/00 9:31 PM Organizer The Organizer feature enables you to:. Write your schedule or to do list.

Calculate. Check the calendar. Play games. Set the current date and time.

Set the alarm so that the phone rings at a specific time (to remind you of an appointment for example). 2488E-13-Menus7 6/7/00 9:31 PM O r g a n i z e r If you select a date when a schedule has already been created you will see the contents. The following options are available: Add: allows you to add new contents. For details on entering a text, see page 41. 2488E-13-Menus7 6/7/00 9:31 PM O r g a n i z e r Alarm This option allows you to set the alarm to ring at a specific time.

The following alarms are available. You can set one or more alarms. Daily Alarm: the alarm rings (at the same time) every day. 2488E-13-Menus7 6/7/00 9:31 PM O r g a n i z e r To do List This menu allows you to write job list with priority and deadline, and also sort the jobs according to their priority type or their status. If you don’t have any items in the list, proceed as follows to make your job list. 2488E-13-Menus7 6/7/00 9:31 PM O r g a n i z e r Play: allows you to start a game.

Level: appears when it is needed. It allows you to select the level. Select the desired level with up/down volume key on the left side of the phone and press the OK soft key. 2488E-13-Menus7 6/7/00 9:31 PM Page 114 O r g a n i z e r Set Time Menu 7-8 The option allows you to change the time displayed, using the 24-hour system. N o t e: B e f o re setting the time, you must specify your time zone, via the World Ti m e menu option (7 - 7). 2488E-13-Menus8 6/7/00 9:31 PM Page 115 Security The Security feature enables you to restrict the use of your phone to:.

The people of your choice. The types of calls of your choice Various codes and passwords are used to protect the features of your phone. 2488E-13-Menus8 6/7/00 9:31 PM S e c u r i t y Change PIN This feature allows you to change your current PIN to a new one, provided that the PIN Check feature is enabled. You must enter the current PIN before you can specify a new one. 2488E-13-Menus8 6/7/00 9:31 PM S e c u r i t y FDN Mode The FDN(Fixed Dial Number) mode, if supported by your SIM card, allows you to restrict your outgoing calls to a limited set of phone numbers. The following options are available.

Enable: you can only call phone numbers stored in the phonebook. 2488E-14-Menu9 6/7/00 9:31 PM Network Services These menu functions are network services. Please contact your service provider to check their availability and subscribe to them, if you so wish. Call Diverting This network service enables incoming calls to be rerouted to the number that you specify.

Example: You may wish to divert your business calls to a colleague while you are on holiday. 2488E-14-Menu9 6/7/00 9:31 PM Network Services To set your call diverting options, proceed as follows. Select the type of call diverting required by pressing until the appropriate option is highlighted, and then press Select. Select the type of calls to be diverted by pressing until the appropriate option is highlighted and then press Select. 2488E-14-Menu9 6/7/00 9:31 PM Network Services 4. Enter your call barring password supplied by your service provider. The phone sends your settings to the network and the network’s acknowledgement is displayed.

To deactivate specific call barring settings, proceed as follows. 2488E-14-Menu9 6/7/00 9:31 PM Network Services Network Selection The Network Selection feature enables you to:. Indicate whether the network used when roaming (outside your home area) is selected automatically or manually. Set up a preferred list to be used when selecting a network automatically Note: You can select a network other than your home network only if it has a valid ro a m i n g. 2488E-14-Menu9 6/7/00 9:31 PM Network Services Line Identification This menu option lets you view the following line identification settings. CLIP (Calling Line Identification Presentation) / COLP (Connected Line Identification Presentation) If these network functions are active, the caller’s number is displayed during a call.

If the phone number matches one stored in the phonebook, the caller’s name is also displayed. 2488E-15-ProblemSolution 6/7/00 Solving Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary service call. When you switch your phone on, the following messages appear Insert SIM Card. The model and serial numbers of your phone. Your warranty details.

A clear description of the problem Then contact your local dealer or SAMSUNG after-sales service. 9:34 PM Page 130 Your phone is powered by a re c h a rgeable Li-ion s t a n d a rd battery. Using the Batteries. Use only Samsung-approved batteries and re c h a rge your battery only with Samsung-appro v e d c h a rgers.

When a charger is not in use, disconnect it from the power source. Do not leave the battery connected to a charger for more than a week, since overc h a rging may shorten its life. 2488E-16-SafetyInformation 6/7/00 Safety Information Road Safety. Remember, road safety always comes first!. Do not use a hand-held phone while driving a vehicle. Always park the vehicle before having a conversation.

Make sure that the phone is stored safely and will not fall or be broken in the event of a collision or emergency stop. 2488E-16-SafetyInformation 6/7/00 Safety Information phone whenever it is forbidden to use it, or when it may cause interference or danger (in a hospital for example). Operation of any radio transmitting equipment, including cellular phones, may interfere with inadequately protected medical devices. Consult a physician or the manufacturer of the medical device if you have any questions. 2488E-16-SafetyInformation 6/7/00 Safety Information. Do not use harsh chemicals, cleaning solvents or s t rong detergents to clean the phone. Wipe it with a soft cloth slightly dampened in mild, soapy water.

If the phone or any of its accessories are not working properly, take them to your nearest qualified service centre. 2488E-17-Glossary 6/7/00 9:34 PM Glossary of Terms To help you understand the main technical terms and abbreviations used in this booklet and take full advantage of the features on your mobile phone, here are a few definitions. Active Flip Ability to voice dial or voice command immediately on opening the flip cover on the phone. 2488E-17-Glossary 6/7/00 9:34 PM Glossary of Terms GSM (Global System for Mobile Communication) International standard for cellular communication, guaranteeing compatibility between the various network operators. GSM covers most European countries and many other parts of the world.

Line Identification Services Service allowing subscribers to view or block the telephone numbers of callers. 2488E-17-Glossary 6/7/00 9:34 PM Glossary of Terms Soft Keys Keys marked. On the phone, the purpose of which:. Varies according to the function that you are currently using. Is indicated on the bottom line of the display just above the corresponding key Voice Mail Computerised answering service that automatically. 2488E-18-Index 6/7/00 9:33 PM Index searching for a number in Access codes. 22 time (2-4).

80 Accessories. 9 via the phonebook. 27 Active Flip (6-0). 103 waiting (9-3). 123 Alarm (7-3). 108 Care.

135 Alert Type (5-4). 2488E-18-Index 6/7/00 9:33 PM I n d e x Letters entering. 41 Earphone.

25 Line Identification (9-5). 126 Earpiece Locking adjusting the volume. 28 phone (8-3). 116 Emergency calls. 8; 136 SIM card (8-5).

117 Error Tone (5-7). 2488E-18-Index 6/7/00 9:33 PM I n d e x SIM card Voice functions (4). 88 installing.

16 Voice language locking (8-5). 117 selecting. 100 precautions. 16 Voice mail SIM Lock (8-5). 117 connecting to (1-1). 77 server number (1-2).

2488E-18-Index 6/7/00 9:34 PM Page 146.

. DUAL BAND Mobile Cellular Phone SGH-2488 SERVICE Manual DUAL BAND Mobile Cellular Phone CONTENTS 1. Exploded Views and Parts List 2. Electrical Parts List 3.

Block Diagrams 4. PCB Diagrams 5. Schematic Diagrams A B C D EF G H I. ELECTRONICS Samsung Electronics Co.,Ltd. Printed in Korea 11/1999 Rev 1.0 GH68-00844A. E-GSM: RX: Fdl(n) = Ful(n) + 45MHz 1710.2 MHz 1784.8 MHz DCS Tx: Ful(n) = 1710MHz + (0.2MHz). (n-511) n = ARFCN, 512≤n≤885 DCS Rx: Fdl(n) = Ful(n) + 95MHz 1805.2 MHz 1879.8 MHz Samsung Electronics.

MS, transferring cell information to MS on downlink, transferring the information about RX level, Quality, and RX level of adjacent cell on uplink. FACCH (Fast Associated Control Channel) steals and changes the TCH when needing a Handover. SDCCH (Stand-alone Dedicated Control Channel) and RACH (Random Access Channel) operate during the call setup procedure. Samsung Electronics. The RF output passes to the antenna connector via an integrated TX/RX switch and lowpass filter to attenuate the harmonics generated by the power amplifier. Samsung Electronics. Exploded Views and Parts List 1-1 Main Exploded View (SGH-2488) Samsung Electronics.

GH73-00188A RUBBER MIC GH73-00189A SPONGE MIC GH74-00355A SPONGE CONNECTOR GH74-00402A SPONGE SPEAK GH74-00403A PM0-SHIELD COVER GH72-00591A PBA MAIN GH92-00878A RMO-CONNECTOR COVER GH73-40673G MOTOR GH31-10004A ANTENNA GH42-00038A SCREW-MACHINE 6001-001148 5PCS RUBBER CAP GH73-00191A BATTERY GH43-00143D 750mAh BATTERY GH43-00183D 1000mAh Samsung Electronics. 1-3 Travel Adapter 1-4 Travel Adapter Parts List TYPE SEC CODE REMARK GH96-01143A CHINA GH96-01146A EUROPE GH96-01095A UNITED KINGDOM Exploded Views and Parts List. 1-5 Desk Top Charger SEC CODE: GH44-00090B Exploded Views and Parts List. 1-6 Desk Top Charger Parts List DESCRIPTION SEC.CODE Q’TY REMARK UPPER CASE HANGER SPRING (L) SCREW TAPPING HANGER SPRING(R) SCREW TAPPING BATT. HOUSING LOWER BASE SCREW TAPPING BUMPON LABEL Exploded Views and Parts List. 1-7 Ciger Light Adapter 1-8 Ciger Light Adapter Parts List DESCRIPTION SEC CODE REMARK Ciger Light Adapter Code GH44-00040A BLACK Exploded Views and Parts List.

1-9 Hands Free Kit SEC CODE: GH96-00800A Exploded Views and Parts List. 1-10 Test Jig TEST JIG GH80-10508A DATA CABLE GH39-30532A 1-11 Earphone EARPHONE GH96-00830A Exploded Views and Parts List. 2 Electrical Parts List 2-1 Main Parts List SEC.CODE DESCRIPTIONS REFERENCE D401,D801 0401-001033 Diode-Switching,25V,200mA D253,D255,D808 0404-001044 Diode-Schottky,20V,1A,SMD D400 0404-001054 Diode-Schottky,70V,15mA,SOT-143 D600 0405-001051 Diode-Varactor,4.7V,50nA,SOT-23 D101,D102,D176,D820,D903,D904 0406-001084 ESD Diode D252 0407-001002 Diode-Array,80V,300mA,CA2-3 D901,D902 0407-001006 Diode-Array,20V,100mA,C2-3 D251 0407-001007 Diode-Array,80V,25mA,CA4-2 Q959 0501-000162 TR-SMALL SIGNAL,PNP,200mW,SOT-323 Q958 0501-000462 TR-SMALL SIGNAL,PNP,225mW,SOT.

SEC.CODE DESCRIPTIONS REFERENCE U960 1202-001022 IC-VOLTAGE COMP,SSOP,8P,110MIL,7V U804 1203-001256 IC-SWITCH VOL REG,SOT-23,5P,59MI U801,U803,U805,U806,U810,U811 1203-001285 IC-SWITCH VOL REG,SOT-23,5P,150MIl U809 1203-001511 IC-Reset,SOT-23,3P U253 1203-001515 IC-BATTERY,SSOP,16P,150MIL U812 1203-001702 IC-DC/DC CONVERTER,SOP,10P,112MIL U102 1203-001740 IC-DC/DC CONVERTER,SOP,16P,150MIL U301 1204-001006 IC-IP SYSTEM,SOP,20P,205MIL U300,U305 1205-001307 IC-MIXER,SOP,16,197MIL U200 1205-001643 IC-KERNEL U950 1205-001697.
